• Wheels, 18" x 8.5" (45.7 cm x 21.6 cm) Bright Silver painted aluminum
• Tires, 265/65R18SL all-season, blackwall
• Wheel, 17" x 8" (43.2 cm x 20.3 cm) full-size, steel spare
• Tire, spare 265/70R17SL all-season, blackwall
• Tire carrier lock, keyed cylinder lock that utilizes same key as ignition and door
• Bumper, front (Body-color.)
• Bumper, rear (Body-color.)
• CornerStep, rear bumper
• Recovery hooks, front, frame-mounted, black
• Cargo tie downs (12), fixed rated at 500 lbs per corner
• Grille (Body color bars with high gloss Black mesh inserts.)
• Black Bowtie, (front grille)
• Headlamps, LED reflector with LED signature Daytime Running Lamps
• Fog lamps, front, LED
• Lamps, cargo area, cab mounted integrated with center high mount stop lamp, with switch in bank on left side of steering wheel
• LED Cargo Area Lighting located in pickup bed, activated with switch on center switch bank or key fob
• Taillamps, LED with signature
• Mirrors, outside heated power-adjustable (When (PQB) Safety Package is ordered, includes Perimeter Lighting.)
• Mirror caps, painted (High gloss Black.)
• Glass, deep-tinted
• Door handles, body-color
• Tailgate and bed rail protection cap, top
• Tailgate, gate function manual with EZ Lift, includes power lock and release

• Audio system, Chevrolet Infotainment 3 system 8" diagonal color touchscreen, AM/FM stereo. Additional features for compatible phones include: Bluetooth® audio streaming for 2 active devices, voice command pass-through to phone, Apple CarPlay and Android Auto capable.
• Audio system feature, 6-speaker system
• Bluetooth® for phone, connectivity to vehicle infotainment system
• Chevrolet 4G LTE and available built-in Wi-Fi hotspot offers a fast and reliable Internet connection for up to 7 devices; includes data trial for 1 month or 3GB (whichever comes first) (Available Wi-Fi requires compatible mobile device, active OnStar service and data plan. Data plans provided by AT&T. Visit onstar.com for details and system limitations.)
• USB ports, 2 (first row) located on instrument panel

• Seats, front 40/20/40 split-bench with covered armrest storage and under-seat storage (lockable) (Not available with (PCH) Convenience Package with Bucket Seats.)
• Seat trim, Cloth
• Seat adjuster, driver 4-way manual
• Seat adjuster, passenger 4-way manual
• Seat, rear 60/40 folding bench (folds up), 3-passenger (includes child seat top tether anchor)
• Floor covering, color-keyed carpeting
• Floor mats, rubberized vinyl, front (Deleted when LPO floor liners are ordered.)
• Floor mats, rubberized vinyl rear (Deleted when LPO floor liners are ordered.)
• Steering wheel, urethane
• Steering wheel audio controls
• Steering column, Tilt-Wheel, manual with wheel locking security feature
• Steering column, lock control, electrical
• Driver Information Center, 4.2" diagonal color display includes driver personalization
• Exterior Temperature Display located in radio display
• Compass located in instrument cluster
• Rear Seat Reminder
• Window, power front, drivers express up/down
• Window, power front, passenger express down
• Windows, power rear, express down
• Door locks, power
• Remote vehicle starter system
• Keyless Open and Start
• Cruise control, electronic with set and resume speed, steering wheel-mounted
• Theft-deterrent system, unauthorized entry
• Air conditioning, single-zone manual, semi-automatic
• Air vents, rear, heating/cooling
• Defogger, rear-window electric
• Power outlet, front auxiliary, 12-volt
• Mirror, inside rearview, manual tilt
• Assist handles front A-pillar mounted for driver and passenger, rear B-pillar mounted
• Power outlet, rear auxiliary, 12-volt
• USB ports, dual, charge-only (2nd row)

• StabiliTrak, stability control system with Proactive Roll Avoidance and traction control, includes electronic trailer sway control and hill start assist
• Daytime Running Lamps with automatic exterior lamp control
• Airbags, dual-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front and rear outboard seating positions; Includes front outboard Passenger Sensing System for frontal outboard passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
• OnStar and Chevrolet connected services capable (Fleet orders receive a 3-month trial. Visit onstar.com for coverage map, details and system limitations. Services vary by model.)
• Chevrolet Connected Access with 10 years of standard connectivity which enables services such as, Vehicle Diagnostics, Dealer Maintenance Notification, Chevrolet Smart Driver, Marketplace and more (Limitations apply. Not transferable. Standard connectivity available to original purchaser for ten years from the vehicle delivery date for model year 2018 or newer Chevrolet vehicles. See onstar.com for details and further plan limitations. Connected Access does not include emergency or security services. Availability and any additional services enabled by Connected Access are subject to change.)
• Rear Vision Camera
• Teen Driver configurable feature that lets you activate customizable vehicle settings associated with a key fob, to encourage safe driving behavior. It can limit certain vehicle features, and it prevents certain safety systems from being turned off. An in-vehicle report card gives you information on your teen's driving habits and helps you to continue to coach your new driver
• Tire Pressure Monitoring System with Tire Fill Alert (does not apply to spare tire)

ENGINE, 2.7L TURBO ($0)

(310 hp @ 5600 rpm 348 lb-ft of torque @ 1500 rpm) (STD)

• WHEELS 18 X 8.5 (45.7 CM X 21.6 CM) BRIGHT SILVER PAINTED ALUMINUM (STD)
• DIFFERENTIAL HEAVY-DUTY LOCKING REAR
• STEERING COLUMN MANUAL TILT AND TELESCOPING
• REAR AXLE 3.42 RATIO
• ALL-STAR EDITION includes (PCL) Convenience Package (G80) locking rear differential and (Z82) Trailering Package
• SEAT ADJUSTER DRIVER 10-WAY POWER INCLUDING LUMBAR
• TRAILERING PACKAGE includes trailer hitch 7-pin and 4-pin connectors and (CTT) Hitch Guidance
• GVWR 6800 LBS. (3084 KG) (STD)
• SEATS FRONT 40/20/40 SPLIT-BENCH with covered armrest storage and under-seat storage (lockable) (STD)
• STEERING WHEEL HEATED
• WHEELHOUSE LINERS REAR
• TIRES 265/65R18SL ALL-SEASON BLACKWALL (STD)
• TRANSMISSION 8-SPEED AUTOMATIC ELECTRONICALLY CONTROLLED with overdrive and tow/haul mode. Includes Cruise Grade Braking and Powertrain Grade Braking (STD)
• BED PROTECTION PACKAGE includes (B1J) wheel house liners and (CGN) Chevytec spray-on bedliner
• STEERING WHEEL LEATHER-WRAPPED
• SEATING HEATED DRIVER AND FRONT PASSENGER
• AIR CONDITIONING DUAL-ZONE AUTOMATIC CLIMATE CONTROL
• CONVENIENCE PACKAGE includes (CJ2) dual-zone automatic climate control (A2X) 10-way power driver seat including power lumbar (KA1) heated driver and passenger seats (NP5) leather-wrapped steering wheel (KI3) heated steering wheel and (N37) manual tilt/telescoping steering column
• ENGINE 2.7L TURBO (310 hp @ 5600 rpm 348 lb-ft of torque @ 1500 rpm) (STD)
• BLACK
• JET BLACK CLOTH SEAT TRIM
• RST PREFERRED EQUIPMENT GROUP includes standard equipment
• AUDIO SYSTEM CHEVROLET INFOTAINMENT 3 SYSTEM 8 diagonal color touchscreen AM/FM stereo. Additional features for compatible phones include: Bluetooth® audio streaming for 2 active devices voice command pass-through to phone Apple CarPlay and Android Auto capable. (STD)
• CHEVYTEC SPRAY-ON BEDLINER BLACK WITH CHEVROLET LOGO (does not include spray-on liner on tailgate due to Black composite inner panel)
• HITCH GUIDANCE
• Turbocharged
• Rear Wheel Drive
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Aluminum Wheels
• Tires - Front All-Season
• Tires - Rear All-Season
• Tires - Front All-Season
• Tires - Rear All-Season
• Tow Hooks
• Daytime Running Lights
• Fog Lamps
• Heated Mirrors
• Power Mirror(s)
• Privacy Glass
• AM/FM Stereo
• MP3 Capability
• Bluetooth® Connection
• Auxiliary Audio Input
• Smart Device Integration
• Bluetooth® Connection
• WiFi Hotspot
• MP3 Capability
• Auxiliary Audio Input
• Split Bench Seat
• Cloth Seats
• Pass-Through Rear Seat
• Rear Bench Seat
• Floor Mats
• Floor Mats
• Steering Wheel Audio Controls
• Adjustable Steering Wheel
• Power Windows
• Power Windows
• Power Door Locks
• Remote Engine Start
• Keyless Entry
• Power Door Locks
• Keyless Start
• Cruise Control
• Security System
• A/C
• A/C
• Rear A/C
• Rear Defrost
• Power Outlet
• Power Outlet
• Traction Control
• Stability Control
• Daytime Running Lights
• Driver Air Bag
• Passenger Air Bag
• Front Side Air Bag
• Front Head Air Bag
• Rear Head Air Bag
• Passenger Air Bag Sensor
• Telematics
• Requires Subscription
• Back-Up Camera
• Driver Restriction Features
• Tire Pressure Monitor

• Mileage
• Fuel Economy Est-Combined (MPG): 21
• EPA Fuel Economy Est - City (MPG): 20
• EPA Fuel Economy Est - Hwy (MPG): 23
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 730
• Maximum Alternator Capacity (amps): 220
• Cooling System
• Total Cooling System Capacity (qts): - TBD -
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3700
• Gross Axle Wt Rating - Rear (lbs): 3800
• Curb Weight - Front (lbs): 2734
• Curb Weight - Rear (lbs): 1864
• Gross Vehicle Weight Rating Cap (lbs): 6800
• Gross Combined Wt Rating (lbs): 12000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 7000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 700
• Maximum Trailering Capacity (lbs): 11600
• Suspension
• Suspension Type - Front: Independent
• Suspension Type - Rear: Solid Axle
• Spring Capacity - Front (lbs): - TBD -
• Spring Capacity - Rear (lbs): - TBD -
• Axle Type - Front: - TBD -
• Axle Type - Rear: - TBD -
• Axle Capacity - Front (lbs): - TBD -
• Axle Capacity - Rear (lbs): - TBD -
• Axle Ratio (:1) - Rear: 3.42
• Shock Absorber Diameter - Front (mm): 50.0
• Shock Absorber Diameter - Rear (mm): 50.0
• Stabilizer Bar Diameter - Front (in): 1.30
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 13.5 x 1.18
• Rear Brake Rotor Diam x Thickness (in): 13.6 x 0.79
• Tires
• Front Tire Order Code: QDF
• Rear Tire Order Code: QDF
• Spare Tire Order Code: XCQ
• Front Tire Size: 265/65R18SL
• Rear Tire Size: 265/65R18SL
• Spare Tire Size: 265/70R17SL
• Front Tire Capacity (lbs): - TBD -
• Rear Tire Capacity (lbs): - TBD -
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: N/A
• Revolutions/Mile @ 45 mph - Rear: N/A
• Revolutions/Mile @ 45 mph - Spare: N/A
• Wheels
• Front Wheel Size (in): 18 x 8.5
• Rear Wheel Size (in): 18 x 8.5
• Spare Wheel Size (in): 17 x 8
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Electric Rack & Pinion
• Steering Ratio (:1), On Center: - TBD -
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 46.3
• Turning Diameter - Wall to Wall (ft): N/A
• Frame
• Frame Type: - TBD -
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 24
• Fuel Tank Location: - TBD -
• Exterior Dimensions
• Wheelbase (in): 147.45
• Length, Overall (in): 231.7
• Width, Max w/o mirrors (in): 81.24
• Height, Overall (in): 75.6
• Overhang, Front (in): - TBD -
• Overhang, Rear w/o bumper (in): - TBD -
• Front Bumper to Back of Cab (in): - TBD -
• Cab to Axle (in): - TBD -
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): - TBD -
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 7.89
• Ground Clearance, Rear (in): 7.89
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 79.44
• Cargo Box Width @ Top, Rear (in): - TBD -
• Cargo Box Width @ Floor (in): 71.4
• Cargo Box Width @ Wheelhousings (in): 50.63
• Cargo Box (Area) Height (in): 22.4
• Tailgate Width (in): - TBD -
• Cargo Volume (ft³): 71.7
• Ext'd Cab Cargo Volume (ft³): - TBD -
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 43.03
• Front Leg Room (in): 44.53
• Front Shoulder Room (in): 66.02
• Front Hip Room (in): 61.18
• Second Head Room (in): 39.88
• Second Leg Room (in): 35.24
• Second Shoulder Room (in): 64.88
• Second Hip Room (in): 60.24
• Summary
• Vehicle Name: Chevrolet Silverado 1500
• Body Style: Double Cab Pickup
• Body Code: E63
• Emissions
• Tons/yr of CO2 Emissions @ 15K mi/year: 8.4
